Lathe Machine Mini Lathe C0632A-TOP C0636A - TOP Metal Lathe Machine
◆ Precision ground hardened bedways ◆ The spindle is supported wish precision roller bearings ◆ Headstock gears are made of high quality steel, ground and hardened ◆ Removable gap is provided for larger diameter work ◆ Easy operation speed change levers ◆ Easy operating gear box has various feeds and thread cutting function ◆ Two types for selection: with foot stand in reserve or without foot stand Specification | C0632A | C0636A | C0636V | Swing over bed | 330mm(13 ＂ ) | 360mm(14 ＂ ) | 358mm(14 ＂ ) | Swing over cross slide | 198mm(7-25/32 ＂ ) | 224mm(8-13/16 ＂ ) | 223mm(8-25/32 ＂ ) | Swing in gap diameter | 476mm(18-3/4 ＂ ) | 502mm(19-3/4 ＂ ) | 502mm(19-3/4 ＂ ) | Swing in length | 210mm(8-1/4 ＂ ) | 210mm(8-1/4 ＂ ) | 210mm(8-1/4 ＂ ) | Center height | 166mm(6-1/2 ＂ ) | 179mm(7 ＂ ) | 179mm(7 ＂ ) | Admits between | 1000mm(40 ＂ ) | 1000mm(40 ＂ ) | 1000mm(40 ＂ ) | Bed width | 187mm(7-3/8 ＂ ) | 187mm(7-3/8 ＂ ) | 187mm(7-3/8 ＂ ) | Bed length | 1655mm(65-1/8 ＂ ) | 1655mm(65-1/8 ＂ ) | 1655mm(65-1/8 ＂ ) | Bed height | 290mm（11- 13/32 ＂） | 290mm（11- 13/32 ＂） | 290mm（11- 13/32 ＂） | Spindle bore | 38mm(1-1/2 ＂ ) | 38mm(1-1/2 ＂ ) | 38mm(1-1/2 ＂ ) | Spindle nose | D1-4 ＂ | D1-4 ＂ | D1-4 ＂ | Taper in nose | MT NO.5 | MT NO.5 | MT NO.5 | Speeds number | 8 | 8 | 8 | Range of spindle speed | 70-2000 r/min | 70-2000 r/min | 20 ～ 450 or 135 ～ 3000r.p.m | Cross slide width | 130mm（5-3/32 ＂） | 130mm（5-3/32 ＂） | 130mm （5-3/32 ＂） | Cross slide travel | 170mm(6-11/16 ＂ ) | 170mm(6-11/16 ＂ ) | 160mm （6-5/16 ＂） | Compound rest width | 80mm(3-1/8 ＂ ) | 80mm(3-1/8 ＂ ) | 80mm(3-1/8 ＂ ) | Compound rest travel | 95mm(3-9/16 ＂ ) | 95mm(3-9/16 ＂ ) | 95mm(3-9/16 ＂ ) | Lead screw diameter | 22mm(7/8 ＂ ) | 22mm(7/8 ＂ ) | 22mm(7/8 ＂ ) | Lead screw thread | 8T.P.I. or 3mm | 8T.P.I. or 3mm | 8T.P.I. or 3mm | Feed rod diameter | 19mm(3/4 ＂ ) | 19mm(3/4 ＂ ) | 19mm(3/4 ＂ ) | Cutting tool max section | 16mm×16mm (5/8 ＂ ×5/8 ＂ ) | 16mm×16mm (5/8 ＂ ×5/8 ＂ )
| 16mm×16mm (5/8 ＂ ×5/8 ＂ ) | Threads imperial pitches | 34 Nos.4-56 T.P.I | 34 Nos.4-56 T.P.I | 34 Nos.4-56 T.P.I | Threads metric pitches | 26 Nos.0.4-7 M.P | 26 Nos.0.4-7 M.P | 26 Nos.0.4-7 M.P | Longitudinal feeds imperial | 32 Nos.0.002-0.548 ＂ /Rev | 32 Nos.0.002-0.548 ＂ /Rev | 32 Nos.0.002-0.548 ＂ /Rev | Longitudinal feeds metric | 32 Nos.0.052-0.392mm/Rev | 32 Nos.0.052-0.392mm/Rev | 32 Nos.0.052-0.392mm/Rev | Cross feeds imperial | 32 Nos.0.007-0.0187 ＂ /Rev) | 32 Nos.0.007-0.0187 ＂ /Rev) | 32 Nos.0.007-0.0187 ＂ /Rev) | Cross feeds metric | 32 Nos.0.014-0.380mm/Rev | 32 Nos.0.014-0.380mm/Rev | 32 Nos.0.014-0.380mm/Rev | Quill diameter | 32mm (1-1/4 ＂ ) | 32mm (1-1/4 ＂ ) | 32mm (1-1/4 ＂ ) | Quill travel | 100mm(3-15/16 ＂ ) | 100mm(3-15/16 ＂ ) | 100mm (3-15/16 ＂ ) | Quill taper | MT NO.3 | MT NO.3 | MT NO.3 | Main motor | 1.5kW(2HP) | 1.5kW(2HP) | 1.5kW(2HP) |
|
